[tutorial v1.1_110] A conditional disabled boolean variable
Read the tutorial "A conditional disabled boolean variable" in the documentation
Screenshot
Clone and install
To test this tutorial, you need to download this repository and install Rougail:
git clone -b 1.1 https://forge.cloud.silique.fr/stove/rougail-tutorials.git
cd rougail-tutorials
python -m venv venv_rougail
. venv_rougail/bin/activate
pip install rougail-cli rougail-output-exporter rougail-output-doc rougail-user-data-yaml
Then switch to the tutorial page:
git switch --detach v1.1_110
Structure
.
├── firefox
│ ├── 00-proxy.yml
│ ├── 10-manual.yml
│ ├── 20-manual.yml
│ ├── 30-auto.yml
│ ├── 40-no_proxy.yml
│ └── 50-prompt_authentication.yml
└── types
└── proxy
└── 00-type.yml
Contents of the firefox/50-prompt_authentication.yml file
%YAML 1.2
---
version: 1.1
prompt_authentication:
description: Prompt for authentication if password is saved
default: true
disabled:
variable: _.proxy_mode
when: No proxy
...
Let's generate the documentation```shell
rougail -m firefox/ --types types/proxy -o doc
| Variable | Description |
|------------------------------------------------------------------------------------------------------------------------------------------------------------|------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| **<a id="proxy_mode" name="proxy_mode">proxy_mode</a>**<br/>[`choice`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Configure Proxy Access to the Internet.<br/>**Choices**: <br/>• No proxy **← (default)**<br/>• Auto-detect proxy settings for this network<br/>• Use system proxy settings<br/>• Manual proxy configuration<br/>• Automatic proxy configuration URL |
#### Manual proxy configuration
> [!NOTE]
>
> **Path**: manual\
> *`disabled`*\
> **Disabled**: when the variable "[Configure Proxy Access to the Internet](#proxy_mode)" hasn't the value "Manual proxy configuration".
##### HTTP Proxy
> [!NOTE]
>
> **Path**: manual.http_proxy
| Variable | Description |
|-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| **<a id="manual.http_proxy.address" name="manual.http_proxy.address">manual.http_proxy.address</a>**<br/>[`domainname`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy address.<br/>**Validators**: <br/>• type domainname<br/>• the domain name can be an IP |
| **<a id="manual.http_proxy.port" name="manual.http_proxy.port">manual.http_proxy.port</a>**<br/>[`port`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy port.<br/>**Validators**: <br/>• well-known ports (1 to 1023) are allowed<br/>• registred ports (1024 to 49151) are allowed<br/>• private ports (greater than 49152) are allowed<br/>**Default**: 8080 |
| Variable | Description |
|-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|------------------------------------------------------|
| **<a id="manual.use_for_https" name="manual.use_for_https">manual.use_for_https</a>**<br/>[`boolean`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Also use this proxy for HTTPS.<br/>**Default**: true |
##### HTTPS Proxy
> [!NOTE]
>
> **Path**: manual.https_proxy\
> *`hidden`*\
> **Hidden**: when the variable "[Also use this proxy for HTTPS](#manual.use_for_https)" has the value "true".
| Variable | Description |
|----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| **<a id="manual.https_proxy.address" name="manual.https_proxy.address">manual.https_proxy.address</a>**<br/>[`domainname`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy address.<br/>**Validators**: <br/>• type domainname<br/>• the domain name can be an IP<br/>**Default**: the value of the variable "[Proxy address](#manual.http_proxy.address)". |
| **<a id="manual.https_proxy.port" name="manual.https_proxy.port">manual.https_proxy.port</a>**<br/>[`port`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy port.<br/>**Validators**: <br/>• well-known ports (1 to 1023) are allowed<br/>• registred ports (1024 to 49151) are allowed<br/>• private ports (greater than 49152) are allowed<br/>**Default**: the value of the variable "[Proxy port](#manual.http_proxy.port)". |
##### SOCKS Proxy
> [!NOTE]
>
> **Path**: manual.socks_proxy
| Variable | Description |
|----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| **<a id="manual.socks_proxy.address" name="manual.socks_proxy.address">manual.socks_proxy.address</a>**<br/>[`domainname`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy address.<br/>**Validators**: <br/>• type domainname<br/>• the domain name can be an IP<br/>**Default**: the value of the variable "[Proxy address](#manual.http_proxy.address)". |
| **<a id="manual.socks_proxy.port" name="manual.socks_proxy.port">manual.socks_proxy.port</a>**<br/>[`port`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | Proxy port.<br/>**Validators**: <br/>• well-known ports (1 to 1023) are allowed<br/>• registred ports (1024 to 49151) are allowed<br/>• private ports (greater than 49152) are allowed<br/>**Default**: the value of the variable "[Proxy port](#manual.http_proxy.port)". |
| **<a id="manual.socks_proxy.version" name="manual.socks_proxy.version">manual.socks_proxy.version</a>**<br/>[`choice`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` | SOCKS host version used by proxy.<br/>**Choices**: <br/>• v4<br/>• v5 **← (default)** |
| Variable | Description |
|-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| **<a id="auto" name="auto">auto</a>**<br/>[`web address`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` *`disabled`* | Automatic proxy configuration URL.<br/>**Validators**: <br/>• well-known ports (1 to 1023) are allowed<br/>• registred ports (1024 to 49151) are allowed<br/>• type domainname<br/>• the domain name can be a hostname<br/>**Disabled**: when the variable "[Configure Proxy Access to the Internet](#proxy_mode)" hasn't the value "Automatic proxy configuration URL". |
| **<a id="no_proxy" name="no_proxy">no_proxy</a>**<br/>[`domainname`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `multiple` *`disabled`* `unique` | Address for which proxy will be desactivated.<br/>Connections to localhost, 127.0.0.1/8 and ::1 are never proxied.<br/>**Validators**: <br/>• type domainname<br/>• the domain name can starts by a dot<br/>• the domain name can be a hostname<br/>• the domain name can be an IP<br/>• the domain name can be network in CIDR format<br/>**Examples**: <br/>• .mozilla.org<br/>• .net.nz<br/>• 192.168.1.0/24<br/>**Disabled**: when the variable "[Configure Proxy Access to the Internet](#proxy_mode)" has the value "No proxy". |
| **<a id="prompt_authentication" name="prompt_authentication">prompt_authentication</a>**<br/>[`boolean`](https://rougail.readthedocs.io/en/latest/variable.html#variables-types) `mandatory` *`disabled`* | Prompt for authentication if password is saved.<br/>**Default**: true<br/>**Disabled**: when the variable "[Configure Proxy Access to the Internet](#proxy_mode)" has the value "No proxy". |
***
### Let's generate the changelog```shell
rougail -m firefox/ --types types/proxy -o doc --doc.contents changelog --doc.changelog.previous_json_file previous.yml
New variable
| Variable | Description |
|---|---|
prompt_authenticationboolean mandatory disabled |
Prompt for authentication if password is saved. Default: true Disabled: when the variable "Configure Proxy Access to the Internet" has the value "No proxy". |
User datas### Example 1#### config/01/config.yml
---
Output```shell
rougail -m firefox/ --types types/proxy -u yaml -yf config/01/config.yml
> [!NOTE]
>
> **Caption:**
> - Variable
> - <span style="color: #B8860B">Default value</span>
Variables:
- :notebook: proxy_mode (Configure Proxy Access to the Internet): <span style="color: #B8860B">No proxy</span>
***
### Example 2#### config/02/config.yml
```yml
---
proxy_mode: Manual proxy configuration
manual:
http_proxy:
address: http.proxy.net
Output```shell
rougail -m firefox/ --types types/proxy -u yaml -yf config/02/config.yml
> [!NOTE]
>
> **Caption:**
> - Variable
> - <span style="color: #A52A2A">Unmodifiable variable</span>
> - <span style="color: #B8860B">Default value</span>
> - <span style="color: #006400">Modified value</span>
> - (:hourglass_flowing_sand: Original default value)
Variables:
- :notebook: proxy_mode (Configure Proxy Access to the Internet): <span style="color: #006400">Manual proxy configuration</span> ← loaded from the YAML file "config/02/config.yml" (:hourglass_flowing_sand: No proxy)
- :open_file_folder: manual (Manual proxy configuration)
- :open_file_folder: http_proxy (HTTP Proxy)
- :notebook: address (Proxy address): <span style="color: #006400">http.proxy.net</span> ← loaded from the YAML file "config/02/config.yml"
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: use_for_https (Also use this proxy for HTTPS): <span style="color: #B8860B">true</span>
- :open_file_folder: <span style="color: #A52A2A">https_proxy (HTTPS Proxy)</span>
- :notebook: <span style="color: #A52A2A">address (Proxy address)</span>: <span style="color: #B8860B">http.proxy.net</span>
- :notebook: <span style="color: #A52A2A">port (Proxy port)</span>: <span style="color: #B8860B">8080</span>
- :open_file_folder: socks_proxy (SOCKS Proxy)
- :notebook: address (Proxy address): <span style="color: #B8860B">http.proxy.net</span>
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: version (SOCKS host version used by proxy): <span style="color: #B8860B">v5</span>
- :notebook: no_proxy (Address for which proxy will be desactivated): <span style="color: #B8860B">[]</span>
- :notebook: prompt_authentication (Prompt for authentication if password is saved): <span style="color: #B8860B">true</span>
***
### Example 3#### config/03/config.yml
```yml
---
proxy_mode: Manual proxy configuration
manual:
http_proxy:
address: http.proxy.net
proxy_dns_socks5: true
Output```shell
rougail -m firefox/ --types types/proxy -u yaml -yf config/03/config.yml
> [!WARNING]
>
> - variable or family "proxy_dns_socks5" does not exist so cannot load "proxy_dns_socks5", it will be ignored when loading from the YAML file "config/03/config.yml"
> [!NOTE]
>
> **Caption:**
> - Variable
> - <span style="color: #A52A2A">Unmodifiable variable</span>
> - <span style="color: #B8860B">Default value</span>
> - <span style="color: #006400">Modified value</span>
> - (:hourglass_flowing_sand: Original default value)
Variables:
- :notebook: proxy_mode (Configure Proxy Access to the Internet): <span style="color: #006400">Manual proxy configuration</span> ← loaded from the YAML file "config/03/config.yml" (:hourglass_flowing_sand: No proxy)
- :open_file_folder: manual (Manual proxy configuration)
- :open_file_folder: http_proxy (HTTP Proxy)
- :notebook: address (Proxy address): <span style="color: #006400">http.proxy.net</span> ← loaded from the YAML file "config/03/config.yml"
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: use_for_https (Also use this proxy for HTTPS): <span style="color: #B8860B">true</span>
- :open_file_folder: <span style="color: #A52A2A">https_proxy (HTTPS Proxy)</span>
- :notebook: <span style="color: #A52A2A">address (Proxy address)</span>: <span style="color: #B8860B">http.proxy.net</span>
- :notebook: <span style="color: #A52A2A">port (Proxy port)</span>: <span style="color: #B8860B">8080</span>
- :open_file_folder: socks_proxy (SOCKS Proxy)
- :notebook: address (Proxy address): <span style="color: #B8860B">http.proxy.net</span>
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: version (SOCKS host version used by proxy): <span style="color: #B8860B">v5</span>
- :notebook: no_proxy (Address for which proxy will be desactivated): <span style="color: #B8860B">[]</span>
- :notebook: prompt_authentication (Prompt for authentication if password is saved): <span style="color: #B8860B">true</span>
***
### Example 4#### config/04/config.yml
```yml
---
proxy_mode: Manual proxy configuration
manual:
http_proxy:
address: http.proxy.net
socks_proxy:
version: v4
Output```shell
rougail -m firefox/ --types types/proxy -u yaml -yf config/04/config.yml
> [!NOTE]
>
> **Caption:**
> - Variable
> - <span style="color: #A52A2A">Unmodifiable variable</span>
> - <span style="color: #B8860B">Default value</span>
> - <span style="color: #006400">Modified value</span>
> - (:hourglass_flowing_sand: Original default value)
Variables:
- :notebook: proxy_mode (Configure Proxy Access to the Internet): <span style="color: #006400">Manual proxy configuration</span> ← loaded from the YAML file "config/04/config.yml" (:hourglass_flowing_sand: No proxy)
- :open_file_folder: manual (Manual proxy configuration)
- :open_file_folder: http_proxy (HTTP Proxy)
- :notebook: address (Proxy address): <span style="color: #006400">http.proxy.net</span> ← loaded from the YAML file "config/04/config.yml"
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: use_for_https (Also use this proxy for HTTPS): <span style="color: #B8860B">true</span>
- :open_file_folder: <span style="color: #A52A2A">https_proxy (HTTPS Proxy)</span>
- :notebook: <span style="color: #A52A2A">address (Proxy address)</span>: <span style="color: #B8860B">http.proxy.net</span>
- :notebook: <span style="color: #A52A2A">port (Proxy port)</span>: <span style="color: #B8860B">8080</span>
- :open_file_folder: socks_proxy (SOCKS Proxy)
- :notebook: address (Proxy address): <span style="color: #B8860B">http.proxy.net</span>
- :notebook: port (Proxy port): <span style="color: #B8860B">8080</span>
- :notebook: version (SOCKS host version used by proxy): <span style="color: #006400">v4</span> ← loaded from the YAML file "config/04/config.yml" (:hourglass_flowing_sand: v5)
- :notebook: no_proxy (Address for which proxy will be desactivated): <span style="color: #B8860B">[]</span>
- :notebook: prompt_authentication (Prompt for authentication if password is saved): <span style="color: #B8860B">true</span>
***
