• Summary
• [tutorial v1.1_091] A variable with multiple value (diff)

[tutorial v1.1_092)] A non mandatory variable

View the diff

Read the documentation

Screenshot

Clone and install

To test this tutorial, you need to download this repository and install Rougail:

git clone -b 1.1 https://forge.cloud.silique.fr/stove/rougail-tutorials.git
cd rougail-tutorials
python -m venv venv_rougail
. venv_rougail/bin/activate
pip install rougail-cli rougail-output-exporter rougail-output-doc rougail-user-data-yaml

Then switch to the tutorial page:

git switch --detach v1.1_092

Structure

.
└── firefox
    ├── 00-proxy.yml
    ├── 10-manual.yml
    ├── 20-manual.yml
    ├── 30-auto.yml
    └── 40-no_proxy.yml

Contents of the firefox/40-no_proxy.yml file

%YAML 1.2
---
version: 1.1

no_proxy:
  description: Address for which proxy will be desactivated
  type: domainname
  params:
    allow_ip: true
    allow_cidr_network: true
    allow_without_dot: true
    allow_startswith_dot: true
  multi: true
  mandatory: false
  disabled:
    variable: _.proxy_mode
    when: No proxy
...

Let's generate the documentation

rougail -m firefox/ -o doc

Variable	Description
proxy_mode choice mandatory	Configure Proxy Access to the Internet. Choices: - No proxy ← (default) - Auto-detect proxy settings for this network - Use system proxy settings - Manual proxy configuration - Automatic proxy configuration URL

Manual proxy configuration

manual

disabled

Disabled: when the variable "proxy_mode" hasn't the value "Manual proxy configuration"

HTTP Proxy

manual.http_proxy

Variable	Description
manual.http_proxy.address domainname mandatory	HTTP address. Validator: the domain name can be an IP
manual.http_proxy.port port mandatory	HTTP Port. Validators: - well-known ports (1 to 1023) are allowed - registred ports (1024 to 49151) are allowed - private ports (greater than 49152) are allowed Default: 8080

Variable	Description
manual.use_for_https boolean mandatory	Also use this proxy for HTTPS. Default: true

HTTPS Proxy or SOCKS Proxy

This family builds families dynamically

manual.https_proxy
manual.socks_proxy

hidden

Hidden: in HTTPS case if "_.use_for_https" is set to "true"

Identifiers:
- HTTPS
- SOCKS

Variable	Description
manual.https_proxy.address manual.socks_proxy.address domainname mandatory	HTTPS or SOCKS address. Validator: the domain name can be an IP Default: the value of the variable "manual.http_proxy.address"
manual.https_proxy.port manual.socks_proxy.port port mandatory	HTTPS or SOCKS port. Validators: - well-known ports (1 to 1023) are allowed - registred ports (1024 to 49151) are allowed - private ports (greater than 49152) are allowed Default: the value of the variable "manual.http_proxy.port"
manual.https_proxy.version manual.socks_proxy.version choice mandatory disabled	SOCKS host version used by proxy. Choices: - v4 - v5 ← (default) Disabled: when the identifier is "HTTPS"

Variable	Description
auto web_address mandatory disabled	Automatic proxy configuration URL. Validator: the domain name in web address can be only a hostname Disabled: when the variable "proxy_mode" hasn't the value "Automatic proxy configuration URL"
no_proxy domainname disabled unique multiple	Address for which proxy will be desactivated. Validators: - the domain name can starts by a dot - the domain name can be a hostname - the domain name can be an IP - the domain name can be network in CIDR format Disabled: when the variable "proxy_mode" has the value "No proxy"

Let's generate the changelog

rougail -m firefox/ -o doc --doc.contents changelog

Modified variable

Variable	Description
no_proxy mandatory domainname disabled unique multiple	Address for which proxy will be desactivated. Validators: - the domain name can starts by a dot - the domain name can be a hostname - the domain name can be an IP - the domain name can be network in CIDR format Disabled: when the variable "proxy_mode" has the value "No proxy"

• [tutorial v1.1_093] Examples (diff)
