[tutorial v1.1_103] Examples

Read the tutorial "Examples" in the documentation

Screenshot

Clone and install

To test this tutorial, you need to download this repository and install Rougail:

git clone -b 1.1 https://forge.cloud.silique.fr/stove/rougail-tutorials.git
cd rougail-tutorials
python -m venv venv_rougail
. venv_rougail/bin/activate
pip install rougail-cli rougail-output-exporter rougail-output-doc rougail-user-data-yaml

Then switch to the tutorial page:

git switch --detach v1.1_103

Structure

.
├── firefox
│   ├── 00-proxy.yml
│   ├── 10-manual.yml
│   ├── 20-manual.yml
│   ├── 30-auto.yml
│   └── 40-no_proxy.yml
└── types
    └── proxy
        └── 00_type.yml

Contents of the firefox/40-no_proxy.yml file

%YAML 1.2
---
version: 1.1

no_proxy:
  description: Address for which proxy will be desactivated
  examples:
    - .mozilla.org
    - .net.nz
    - 192.168.1.0/24
  type: domainname
  params:
    allow_ip: true
    allow_cidr_network: true
    allow_without_dot: true
    allow_startswith_dot: true
  multi: true
  mandatory: false
  disabled:
    variable: _.proxy_mode
    when: No proxy
...

---

Let's generate the documentation

rougail -m firefox/ --types types/proxy -o doc

Variable	Description
proxy_mode choice mandatory	Configure Proxy Access to the Internet. Choices: • No proxy ← (default) • Auto-detect proxy settings for this network • Use system proxy settings • Manual proxy configuration • Automatic proxy configuration URL

Manual proxy configuration

Note

Path: manual
disabled
Disabled: when the variable "Configure Proxy Access to the Internet" hasn't the value "Manual proxy configuration"

HTTP Proxy

Note

Path: manual.http_proxy

Variable	Description
manual.http_proxy.address domainname mandatory	Proxy address. Validators: • type domainname • the domain name can be an IP
manual.http_proxy.port port mandatory	Proxy port. Validators: • well-known ports (1 to 1023) are allowed • registred ports (1024 to 49151) are allowed • private ports (greater than 49152) are allowed Default: 8080

Variable	Description
manual.use_for_https boolean mandatory	Also use this proxy for HTTPS. Default: true

HTTPS Proxy

Note

Path: manual.https_proxy
hidden
Hidden: when the variable "Also use this proxy for HTTPS" has the value "true"

Variable	Description
manual.https_proxy.address domainname mandatory	Proxy address. Validators: • type domainname • the domain name can be an IP Default: the value of the variable "Proxy address"
manual.https_proxy.port port mandatory	Proxy port. Validators: • well-known ports (1 to 1023) are allowed • registred ports (1024 to 49151) are allowed • private ports (greater than 49152) are allowed Default: the value of the variable "Proxy port"

SOCKS Proxy

Note

Path: manual.socks_proxy

Variable	Description
manual.socks_proxy.address domainname mandatory	Proxy address. Validators: • type domainname • the domain name can be an IP
manual.socks_proxy.port port mandatory	Proxy port. Validators: • well-known ports (1 to 1023) are allowed • registred ports (1024 to 49151) are allowed • private ports (greater than 49152) are allowed Default: 8080
manual.socks_proxy.version choice mandatory	SOCKS host version used by proxy. Choices: • v4 • v5 ← (default)

Variable	Description
auto web address mandatory disabled	Automatic proxy configuration URL. Validators: • well-known ports (1 to 1023) are allowed • registred ports (1024 to 49151) are allowed • type domainname • the domain name can be a hostname Disabled: when the variable "Configure Proxy Access to the Internet" hasn't the value "Automatic proxy configuration URL"
no_proxy domainname multiple disabled unique	Address for which proxy will be desactivated. Validators: • type domainname • the domain name can starts by a dot • the domain name can be a hostname • the domain name can be an IP • the domain name can be network in CIDR format Examples: • .mozilla.org • .net.nz • 192.168.1.0/24 Disabled: when the variable "Configure Proxy Access to the Internet" has the value "No proxy"

---

Let's generate the changelog

rougail -m firefox/ --types types/proxy -o doc --doc.contents changelog --doc.changelog.previous_json_file previous.yml

Modified variable

Variable	Description
no_proxy domainname multiple disabled unique	Address for which proxy will be desactivated. Validators: • type domainname • the domain name can starts by a dot • the domain name can be a hostname • the domain name can be an IP • the domain name can be network in CIDR format Examples: • .mozilla.org • .net.nz • 192.168.1.0/24 Disabled: when the variable "Configure Proxy Access to the Internet" has the value "No proxy"

---

User datas

Example 1

config/01/config.yml

---

---

Output

rougail -m firefox/ --types types/proxy -u yaml -yf config/01/config.yml

Note

Caption:

• Variable
• Default value

Variables:

• 📓 proxy_mode (Configure Proxy Access to the Internet): No proxy

---

Example 2

config/02/config.yml

---
proxy_mode: Automatic proxy configuration URL
auto: https://auto.proxy.net/wpad.dat
no_proxy:
  - example.net
  - 192.168.1.0/24

---

Output

rougail -m firefox/ --types types/proxy -u yaml -yf config/02/config.yml

Note

Caption:

• Variable
• Modified value
• (⏳ Original default value)

Variables:

• 📓 proxy_mode (Configure Proxy Access to the Internet): Automatic proxy configuration URL ← loaded from the YAML file "config/02/config.yml" (⏳ No proxy)
• 📓 auto (Automatic proxy configuration URL): https://auto.proxy.net/wpad.dat ← loaded from the YAML file "config/02/config.yml"
• 📓 no_proxy (Address for which proxy will be desactivated):
  • example.net ← loaded from the YAML file "config/02/config.yml"
  • 192.168.1.0/24 ← loaded from the YAML file "config/02/config.yml"

---

Example 3

config/03/config.yml

---
proxy_mode: Automatic proxy configuration URL
auto: https://auto.proxy.net/wpad.dat

---

Output

rougail -m firefox/ --types types/proxy -u yaml -yf config/03/config.yml

Note

Caption:

• Variable
• Default value
• Modified value
• (⏳ Original default value)

Variables:

• 📓 proxy_mode (Configure Proxy Access to the Internet): Automatic proxy configuration URL ← loaded from the YAML file "config/03/config.yml" (⏳ No proxy)
• 📓 auto (Automatic proxy configuration URL): https://auto.proxy.net/wpad.dat ← loaded from the YAML file "config/03/config.yml"
• 📓 no_proxy (Address for which proxy will be desactivated): []

---
